Ngaire – South Island

Ngaio Nelson

Ngaire
The above photo was sent in by Lake Rotoiti (Rotorua) boat builder Alan Craig. Alan spotted the photo of Ngaire on a recent trip to the Maritime Museum in Mapua, Nelson. At the time Ngaire was owned by Jack Marusich and he is waiting for a load of sheep to be rowed out to the boat. I have to saw the sheep look remarkably relaxed given the trip. The photo caption commented that they were most likely used to it and were probably being relocated to fresher pasture.  Given the load it must have been a great dinghy.
Anyone able to tell us more about this launch?
And speaking of great dinghies – check out Martin Howson’s new clinker below, built late 2019 by Dave Jackson. She measures 8’ x 4’6” and It is built out of ply and ribbed and riveted, there is no glue. Her ribs are  North American white oak, the breast hook and the quarter knees are oak, the thwarts are kauri and knees for the thwarts are oak as well
The oars at 7 ft and Martin commented that you can really put your back into rowing or just tack it easy.  The floor boards are scribed and are easily removed
for cleaning and again they are made from kauri.
DSCN1926

Ngaio – A Peek Down Below

IMG_4773

IMG_4743

IMG_4752

NGAIO – A Peek Down Below

Last weekend a few woodys gathered in Islington Bay, Rangitoto Island, one of my all time favourites was there – Ngaio the 1921, Arch Logan built, 36‘ launch owned by Jan Barraclough.
Ngaio is such a stunner she couldn’t be from any other designer / builder than Arch Logan. I got to have a peek below – enjoy 🙂
She has made several appearances on WW, links below – her restoration is well documented here.
19-03-2020 Harold Kidd Input – How interesting to see the Logan Bros’ builders’ plate on NGAIO. I assume it was put there by Arch? If so, he was keeping the LOGAN BROS name alive. Of course he would still have had a stock of their builders’ plates but I can’t quite work out his motivation in using one on NGAIO. Robin might care to comment too?
20-03-20 Robin Elliot Input –Sorry I missed this. I have been self-isolating for the past 15 years or so and now it seems the world has caught up with how peaceful it can be.

The Logan plate is Interesting. From the photos in the earlier WW posts, that plate has been there on Ngaio for some time but whether it was there at the time of launching is impossible to say. Doubtful.

I’m not sure if there is one on Doreen/Coquette – I don’t think so – but as you say why would he put one on Ngaio in 1921? He was very ‘proper’ and it just would not have been right.

I suspect that rascally his son Jack was flinging them out when he cleared out the house in Bayswater in the 1950’s and passed one over to the then owner of Ngaio; probably on the grounds that Ngaio was an Arch tweak of a general hull shape developed at Logan Bros?

Interesting that there are 4 small screw holes in the plate around its edge but some philistine has drilled two big boofy holes in the centre for a couple of bog-standard slotted screws. The two empty holes in the timber above the plate lead me to believe there was another item (a different plate?) there before the Logan plate.

It’s not strictly correct but hey, its a nice addition.

RC Yacht Racing
Yesterday while waiting to pick up a family member from the medical centres near North Shore Hosp. I wandered down to Lake Pupuke and spied a group of gents sailing their yachts in the Quarry Lake.
A very pleasant way to fill in 1/2 hr – nearly forgot about the patient 🙂

WBB0003_Banner-980x160

Erinor – A Peek Down Below

Erinor e

Erinor a

Erinor d

ERINOR –  A Peek Down Below

Back in August 2014 Erinor made a brief appearance on WW, link below, lots of chat in the comments section.
What I can tell you is she was built by McGeady in 1953 for Gordon Collie and measures 33’6” x 10’8” x 3’6”. Powered by a Ford 120hp diesel.
In a previous life she was named – Lady Allyson.
Thanks to tme we get to have a peek down below.
Note To Self – Don’t Raft Alongside Trinidad – tends to lead to ‘short pants’ syndrome 🙂
RD+Trinny+Ngaio
WBB0003_Banner-980x160

Woody Waitangi Day Picnic – Photos

P1080161

Scott Colville

P1080150

My Girl & Pacific

P1080139

Monterey

P1080170

Centaurus

P1080168

Mana

P1080158

Ann Michelle

_1080156

Trinidad

P1080133

Arohanui

P1080148

Eileen Patricia

P1080169

Sybil Frances

P1080166

Tusk

P1080163

Shango (Ani)

P1080145

Awatere

P1080144

Sea Fever

_1080155

Ngaio

P1080138

Silvery Main

P1080142

Tuna

P1080147

?

P1080140

Wirihana

_1080153

Very smart new mast on Pacific 🙂

WOODY CLASSICS WAITANGI DAY PICNIC  PHOTOS

Another great Woody Classics Woody event yesterday, we had 20+ classic woodys anchored  in Wakalabubu Bay, Motutapu Island. Most came ashore for the picnic and while the camera stayed in the bag, I can report that these casual events are a winner, so nice to catch up with old friends and meet new ones. Youngest age would have been around 6/7 years and the oldest was 92 !
If I missed getting a photo of your woody, I apologise, but with people coming and going all afternoon I suspect someone missed out.

The breeze picked up later in the day and so most had the old wind against the tide coming home – but it was worth it.
Big thanks to everyone the rocked up – see you all at our next event – details soon 😉
Off to Lake Rotoiti (Nth Island) on Saturday  for the Classic & Wooden Boat Parade – Monday’s WW story should be a goody 🙂

Oops nearly forgot anyone know the launch below, we crossed paths of Rangitoto – terrible photo, grab the phone and unfortunately had it set on some weird setting. Name is something like Tautai ??
WBB0003_Banner-980x160

Auckland Anniversary Day – Classic Launch Race – 26 Wooden Boat Photos

P1080065

Auckland Anniversary Day – Classic Launch Race

Over the long weekend we had a smorgasbord of boating events to chose from, one being a ‘classic’ launch race on the Monday, as part of the 2020 Auckland Anniversary Day Regatta. The format is a handicapped race around a set inner harbour course, effectively a drag race. Handicapping for these races is a challenge, there are so many variables that come into play.
Reviewing the results, the handicapping appears to have done a good job.
The day was near perfect and a delayed start meant that I was able to take the above photos. I was heading back for Mahurangi and was not planning to be at the event.
As you would expect, there were numerous mechanical problems and a few DNF’s.
Photos a little ‘hairy’ – long lens.
Results:
1st:   Ngaio
2nd: Sterling
3rd:  Fancy Free
P1080126

WINNER – NGAIO

P1080117

RUNNER UP – STERLING

P1080121

THIRD PLACE – FANCY FREE

WBB0003_Banner-980x160

Woody Trip To The Riverhead Hotel – 30+ classic wooden boat photos

P1040172

P1040124

P1040185

P1040192

P1040212

P1040263

P1040252

Woody Trip To The Riverhead Hotel

Yesterday, 14 CYA Woody launches got together to visit the Riverhead Hotel, we had a fantastic turn-out with several ’new’ woodys joining in. Of course Jason Prew’s just relaunched – My Girl, had everyones attention, check out the zoom zoom photos above, that girl can move 🙂
A small tide made for some interesting manoeuvres at times, but no one came to grief (for long)
It was great to see the publican – Stephen Pepperell’s magnificently refitted woody – Volantis, alongside the wharf. She is a stunning ship, but the man does have very good taste.
The hotel was buzzing with a band in the garden bar & great food on offer – from those that I talked to, everyone had a great time. Several CYA members travelled by road, including Margaret & Bert Woolicott, our hosts in 2 weeks at Patio Bay for the Xmas weekend cruise / BBQ, which for me is the coolest event on the CYA calendar – see you there on December 1st.
ps if anyone picked up a small white & blue fender on a long rope, with brass clip – its mine – lost it overboard on the trip up, 1/2 way up the creek 😦
waitematawoodys t-shirts orders – don’t be slow in getting your order in, based on the sales to date I will probably close the order book early 😉

Ngaio

ngaio-northcote2

NGAIO
This one (there are a few with that name out there) was spotted off Northcote last weekend by Nathan Herbert, he commented that her bow sheer has hints of the ex Winstone owned, Lidgard built –  Tuarangi > Silver Tip. Details on her at the links below

Todays look   https://waitematawoodys.com/2016/08/24/lidgard-42/

As launched look     https://waitematawoodys.com/2015/06/13/wairangi-2/.

Any of the woodys able to supply more details on Ngaio ?

Bugger

BUGGER

The 1921 classic Arch Logan launch Ngaio got a little close to the eastern end of Flat Island (Gt Barrier) on Monday. She hit just after high tide and given the angle of the ‘dangle’  must have been going at a good pace. I understand the hole(s) were patched and she was floated off on the next tide. She is built like a brick shite house so one can imagine the only major damage would have been a few bruised egos 😉 Click photos to enlarge, sorry crappy photos, mobile phone at a distance.

I for one can not comment – a mooching speed & a big powerful runabout nearby, were my saving grace (different bricks) 🙂

15-01-2016 Owner Report

Luckily Ngaio  was only traveling at 5 knots when she hit and it happened at full high tide. As the tide dropped, Ngaio came to rest almost fully supported along her keel. Salvage operators had her refloated 3 hours before the next high tide. The only damage was to the stem plate which covered the pohutakawa stem underneath, and the sacrificial keel plate. No boards were sprung, no water was taken on, and no other damage. They don’t build boats like that, these days.
The next day she returned to Auckland from Gt Barrier, without missing a beat..

Ngaio – Sailing Sunday

Ngaio – Sailing Sunday
photo ex Nathan Herbert

Todays photos were taken in early Jan 2015 by Nathan & are from Tutukaka. The hauled out ‘yacht’ has an interesting set up – 2 masts + game poles 🙂
I have to say it looks a great spot to haul out.

Anyone able to shed some light on the boat?

No longer a mystery – its Ngaio, designed by Jim Mason in 1941 – photos below from Dean Wright

Harold Kidd Input

In case Ian doesn’t post, she was designed and built by Jim Mason at Grey Street, Whangarei from a half model and launched in 1941. She was partly mobilised in 1942 by NAPS and crewed by Jim Mason, skipper, Tom McKinnon, deputy skipper, and Jack Carpenter, Bob Baker, Peter Roberts and Ian Crawshaw. Her NAPS number was Z40.
These NAPS boats did a great job during wartime when German commerce raiders and minelayers were busy around New Zealand at the start and were followed by Jap submarines checking us out. The Whangarei boats were in the most likely place for trouble.
Lovely boat.

Input from owner & son of builder, Ian Mason

A following up on Harolds post on Ngaio,all correct I might add. She was built over a two year period. She is carvel planked in kauri over kowhai ribs and pohutukawa stem, stern and floors. Her first engine was a 6 cylinder Delage out of a car owned by my father. When it was replaced in 1957 by an air cooled Enfield they got more for the scrap than Dad originally paid for the car. When she was built kauri was 3 pound 15 shillings per 100 super feet and the copper nails were the equivalent of 75c per pound. The original suit of sails cost 25 pound from Sails and Covers. In those days she carried 750 sq ft of sail. Since the Enfield she has been powered by a Ruston, Bedford and now a 6BB1 Isuzu. I installed this in 1995  and we have had 7000 trouble free hours since. I first went aboard Ngaio when I was 4 months old. I have 4 children and 9 (to date) grand children and they all love her as much as those  that have gone before. I think she will keep the same name and family ownership for a while yet.



Classic Reproductions

Classic Reproductions

Today’s post profiles the work of Wayne Spicer, a very talented modeler who has built an impressive number of our classic fleet. Wayne has been modeling for approx. 17 years & is a volunteer model maker at the Maritime Museum in Auckland (on Tuesdays). Wayne has built a number of square riggers including Endeavour, Bounty (3), Victory (3), Spanish galleon.

While at the Museum Wayne meet Rod Marler, the owner of the Logan yacht ‘Little Jim’, Rod commissioned Wayne to build a model of LJ & this got Wayne hooked on Logan boats. Wayne told me that he enjoyed the classic lines of the Logans and how they showed the evolution of sailing designs since the late 1800’s. You will see from the the list below that he has built quite a few.

BUILT TO DATE:

Thelma
Rainbow
Waitangi
Jessie Logan (2)
Little Jim (2)
Tawera (2)
Ariki
Aromoana
Ngaio
Gypsy
Nomad
Ranger
Helen

Most of Wayne’s models are made from scratch which means they are not kit sets, fyi below are some photos of the model making process for Nomad.

This slideshow requires JavaScript.

Restored 1921 Arch Logan Classic Motor Yacht Ngaio For Sale

Arch Logan Classic Ngaio For Sale

In 1921 at Ngataringa Bay, Devonport, New Zealand’s greatest boat designer/builder Arch Logan launched the motor yacht Ngaio that had been commissioned by owner H. Partridge.
Logan built this magnificent kauri carvel planked vessel using full length kauri planks i.e. each plank was 39′ long.

Fast forward 92 years & Ngaio was acquired by Auckland architect Ian Kohler, who with partner Lancia undertook one of the most extensive professional restorations to a classic wooden boat we have seen in recent years. Ngaio’s hull was taken back to bare timber, kauri splined & glassed. Every item of engineering & fitting on-board was either reconditioned or replaced.

The photos above & below do not do this classic justice. If you are in the market for a classic vessel – inspection of Ngaio won’t disappoint.
This is a once in a lifetime chance to acquire a piece of NZ’s maritime heritage & is presented in turn the key, sail away condition.

Call Greg Stenbeck 021 985 830 or e: gregs@gulfgroup.co.nz

PS – This is actually Saturdays post, posted early 🙂

Ngaio below as featured in the 2014/5 Classic Yacht Association Register



Ngaio

NGAIO

Yesterday (10/12/2013) saw the 1921 Arch Logan 36′ motor launch Ngaio relaunched after a extensive re-fit & you will note that she has returned to her original colour scheme, a dark (black) navy blue 🙂 To view Ngaio pre-refit click this link to view a youtube clip from the 2013 CYA Riverhead Hotel Cruise. You cab also view more background by searching the word Ngaio in the ww search box.

http://www.youtube.com/watch?v=nU8zPAsrGa4&feature=youtu.be

Her owners Ian Kohler & wife are CYA members & Ngaio is a spectacular addition to the classic launch fleet in Auckland.

I again quote CYA duty chairman Bruce Tantrum on Ngaio “Her beauty out of the water, as one would imagine, is complete, simple and beautiful. The hull’s multi layered accumulation of many decades of paint has been removed revealing the symmetrical artistry of master craftsman Arch Logan’s full length bare kauri planking, all in absolutely perfect condition. In the next few days, she is going to be splined and fibreglassed above the water line to preserve her.

Never again will this particular definitive testament of material, form and craftsmanship be seen, never”

I myself have a soft spot for her as she has such wonderful lines, but she is a Logan & they were rather good at knocking up these things of beauty.

Boats are like houses & everyone has their own sense of style & taste – & sometimes thats a worry, but I can happily report that the Kohler’s have enhanced all the original features in a way that Arch Logan would have approved of. As you will see from the photos, as she sits on the marina, she is still a work in progress but only needing the final touches to complete the project.

Well done.

Around the yards

This slideshow requires JavaScript.

Eeny, Meeny, Miny, Moe

Which one would I choose  – Trinnidad, Ngaio, Waimiga ?

Well unless, one the owners gets a bang on the head & Big Wednesday smiles on me this week, its a hypothetical question . The answer – any of them could slip into my berth at Bayswater.

Three of the CYA’s prettiest ladies are about to leave the shed after a winter of pampering, o-boy the launch fleet bar just got raised a few notches 🙂

My spies tell me that Lady Crossley is also due back in soon & is also looking very smart.

I’ll post more when they splash.

Ngaio

NGAIO
I’m pleased to be able to announce that after being ‘on-the-market’ for several years, the 1921 Arch Logan 36′ launch Ngaio now has a new owner. She passed her survey with flying colours & has been hauled out & is now safely in a shed for a major external renovation.  As part of the work she will return to her original colour scheme i.e. a dark (black) navy blue. Above are photos of her post launching (possibly taken in Devonport), today – both in the water & at her recent haul-out, a preliminary sketch of her new colour scheme & wonderful scale model built of her by CYA member Bruce Tantrum.
Also click this link to view a youtube clip from the recent CYA Riverhead Cruise.
Her new owner has already applied to join the CYA, so Ngaio will be a wonderful addition to the launch fleet.
We will follow the project with great interest.
26/07/2013 – The restoration begins, photos added of haul out & transport to her new (temporary) home – a boat shed for the work.

Weekend 1

All fittings are off, belting 50% off, mast and stack removed, paint stripping beginning.

Findings so far; pohutakawa stem, kauri carvel planking, original waterline belting line cut into hull, original color is black hull, 13 coats of paint below the belting strip, 6 above the strip.

11/08/2013 – On Bruce Tanturm’s instructions (I always do what BT’s tells me to) I visited the boat shed today & meet the new owners, pleased to report that Ngaio has fallen on her feet 🙂

To quote Bruce “Her beauty out of the water, as one would imagine, is complete, simple and beautiful. The hull’s multi layered accumulation of many decades of paint has been removed revealing the symmetrical artistry of master craftsman Jack Logan’s full length bare kauri planking, all in absolutely perfect condition. In the next few days, she is going to be splined and fibreglassed to preserve her.

Never again will this particular definitive testament of material, form and craftsmanship be seen, never”

I can happliy add that the splining & f/g will only be above the waterline.
