Just to muddy the waters a bit, the NAOMI at Panmure owned by Tim Hanna turns out to be the Logan Bros-built Huria, later owned by Jenny and renamed VANORA. See the discussion on VANORA recently on WW.
New Golden Hind at Kawau Island – Sailing Sunday
Today’s photo is another from the Auckland Museum’s Tudor Collins collection, this one emailed to me by Ken Ricketts. It shows the ‘New Golden Hind’, designed by Chas. Bailey Jr. & built at the Deemings Opua yard. She is anchored off Mansion House Bay, Kawau Island c.1940’s.
Any one able to ID the launches?
You can see more photos & details on her here https://waitematawoodys.com/2016/06/22/new-golden-hind/
JANE – Sailing Sunday
photos & details ex Mike O’Dwyer
Janet was designed by Chas. Bailey Jr. in 1902 & built by the Sutherland brothers in Domain Street, Devonport*. She is now owned by Andrew Wares, Bruce Isles and Michael O’Dwyer of Hawkes Bay. All friends since childhood with a common interest in sailing who decided to obtain a classic yacht – a day sailer, not too big, something with a bit of provenance that had to look nice. After a year of looking Janet came up and fitted the bill.
Janet was purchased in June 2013, shipped to Napier in April 2014 and relaunched in April 2015 after an eighteen month makeover. Almost all of the work being done by Mike O’Dwyer & with limited spare time saw the project sixteen months longer than expected. A brief overview of the project goes like this – she had six planks replaced, three each side in the garboard area, a certain amount of repair completed on the inner skin, and was fully re-caulked, puttied and painted. The keel and rudder were fared and the floors refastened. The rig was also spruced up with the mast being painted, the boom varnished/painted, fittings newly galvanized and the roller reefing system rebuilt. The owners report she sails beautifully and with improvements and tweaks continuing will only get better. In the first photo above she is seen enjoying her first sail in Napier waters.
The restoration goes like this – Janet was stored at the sailing club hardstand with scaffolding around her, the tarp covering the scaffold was originally rented because they thought they would only be there two months to do a spruce up. Well the best laid plans…. After removing the paint with hand scrapers it was discovered that the wide seams were full of sika around the garboard area, a copper strip covered a dodgy seam, planks that looked like they had lost some fastenings. Further raking of seams revealed very old caulking and putty.
In one of the photos you can see below the dark water stained areas that there was a 10mm gap between the garboard plank and the inner skin. Only one thing for it, full re-caulk, putty and new planks. The bottom three on each side had to be replaced.
In another photo you can see a copper strip covering the seam just above the forward edge of the lead keel, the seam behind this was about 10mm wide and full of gunk. The wooden filler block on the leading edge of the keel also needed to be replaced. When raking out a small section of a seam it started with newer cotton on the outer, as you went deeper the cotton got older until finally the last cotton to come out was like a ribbon. The plank edges were parallel to each other back to the inner skin which made for a narrow deep seam. The seams were paid with a variety of products e.g there was black sika,white sika and putty. Up to five layers of caulking( the stranded type) were removed from some seams.
You can also see the scored waterlines in the hull planks. They counted about six of these either side. Janet had an inboard engine at some stage which could account for some of them.
The varnish product on Janet is Hempel diamond varnish & is a two pot varnish. There are five coats on everything that needed varnishing. The wind vane is home made & works a treat.
Below is an index to some of the photos & her owner talks you thru some of the work. Scroll over the photo to view the number. Also remember you can enlarge the photos by clicking on them 😉
Andrew, Bruce & Michael have done a wonderful job in restoring Janet & hopefully we will see her back on the Waitemata for some of the classic yacht regattas.
Mike will be posting some updates & photos on the CYA Forum – link below http://classicyacht.org.nz/cyaforum/topic/janet-back-in-action/
Photo 1 – shows the hull primed and caulked. You can see the lowest three planks that are to be replaced and a rough area where a copper strip was used to cover a wide seam.
Photo 2 – the hull above the waterline puttied. Below the waterline redlead paint was added to the putty.
Photo 3 – planks removed portside. A couple of the planks literally fell off when the end screws were removed. It must have been the corrosive entities handing hands that kept them on.
The inner skin though black from years of bilge water,oil and god knows what else was still sound. Gotta love that kauri. A few kauri shims also fell out,used as packers to take up a few gaps between the skins.
I remedied this with lightweight filler mixed in epoxy. Kauri locks also fitted at fore upper end of the lead keel ready for shaping.
Photo 4 – Inner skin repaired and first plank fitted. The floor fastenings were replaced also.
Photo 5 – Planks awaiting faring. Lots of red lead paste between the skins. Kauri blocks shaped and primed.
Photo 6 – Starboard planking underway. Eight new inner skin plank ends were scarfed in place.
Photo 7 – Bit of bling – I’m letting this oxidize however as I like the vert de gris look. Aging gracefully.
Photo 8 – Just about ready for the water. Still work to do on the rig.
Photo 9 – Not a bad looking rear.
Photo 10 – Happy boat back in the water after 15 months.
Photo 11 – Mast painted by brush. To many scarfs of different coloured timbers so went with the paint option.
*Harold Kidd Input
Angus and William Sutherland lived in Domain Street, Devonport. Angus was a shipwright with Chas. Bailey Jr and had Bailey design two yachts for himself and his sons. The first was JANET in 1902, a 24ft linear rater. The second was the 40 footer WAIONE, built to replace JANET in 1907. She was a 9 metre under the recently-adopted International Rating Rules.
Both yachts were built privately by the Sutherlands at their home in Domain Street, not at Bailey’s yard which, until 1912, was at 43 Customs Street West at the foot of Hobson Street. In November 1912 he moved his yard to the new reclamation at Beaumont Street, Freeman’s Bay.
Confusion arises sometimes because Chas. Bailey Jr DID design and build a JANET about this time, but it was a 30ft linear rater for J. McMurtrie of Sydney. Even then, some sources say she was a Sibbick design.
Your yacht was probably named after the Sydney yacht which was launched in 1901.
03-04-2016 Update – 2016 Art Deco Parade of Sail – A Mark Foy start, Janet claimed line honours.
A.H.B. / KELVIN
A.H.B. is 1907 Chas Bailey Jnr, 3 skin Kauri and 39ft., she was built for the Auckland Harbour Board hence her name A.H.B….Once she was sold out of their ownership she was renamed Kelvin and spent most of her life called that, her current owners, the Pollard brothers, we put her back to her original name.
Paperspast says she’s worked alongside Ferro in the early days, even receiving Ferro’s old engine at one stage. Also that she was leased to the police during night time hours for patrolling the harbour in 1911.
She was transferred to the Manukau and used by their harbour board for quite some time there before being sold off eventually.
The old stern on photo (supplied by Harold Kidd) is thought to be before or after the shot of the other old photo (ex Paperspast ) which caption says she was being returned to the Waitemata to be used in cray fishing industry 1933. Refer b/w photo/caption below.
Some info supplied by CYA member Baden Pascoe even has her fitted with two engines in the late 1940’s. Both shaft logs are still installed but plugged off.
She was also owned for a time by by boat builder Dave Jackson.
For a while she languished amongst the derelict boats down in Waikawa, then she was sold and steamed to Mana where she was forgotten and almost met her end via chainsaw before the Pollards rescued her, got her running / floating and bought her back to Auckland.
She’s powered by a D series Ford with a hydraulic box and is berthed at Panmure. She is mobile but she is a project boat requiring plenty of work and a loving owner to take her to the next step.
The Pollards boys – Andrew & Cameron have rescued more classic motor vessels than anyone I know, I have heard Harold Kidd say on numerous occasions “the their blood is with worth bottling”.
Like all of us, there are only so many toys you can fit in the box so A.H.B. is looking for a new owner / home – initially contact me on firstname.lastname@example.org
as always – click on any photo to enlarge 😉
RONAKI (MV Manukau)
Classic displacement launch designed and built in triple skin heart kauri by Charles Bailey Jnr in 1914 and known as m.v. Manukau, she plied the Manukau Harbour as a pilot boat and was also used for barge work and buoyage. Rebuilt to survey in 1961, she had a new Gardner LW4 diesel installed and for many years was used sounding work in the Waitemata. She is now in private hands and has been lovingly cared for and used as a pleasure boat by her present owner. For sale now on trademe.
The 56 hp Gardner 4 LW drives her along at 7.5-8.5 knots using only an astonishing 4 litres of diesel per hour
Transmission Details: Inboard
Engine Details: 1961 Gardner 4 LW
Displacement: 9900 kg
Beam: 3.16 metres (10 Ft 4 In)
Draft: 1.00 metres (3 Ft 3 In)
Fuel Capacity: 455 litres
Water Capacity: 136 litres
Harold Kidd update 30/03/2014
The info on this launch as set out above is 100% accurate. The first RONAKI was designed and built by Collings & Bell for the Auckland Harbour Board in February 1913 (see “Vintage NZ Launches” for a good image and history). She was converted to a bridgedecker after AHB disposed of her to G Hyauiason and probably got the V8 during RNZN service in WW2.
Since contributors are continually (and drearily) name-dropping on this site, let me join in. It was probably my uncle, Lou Wilson, MD of Watson Steele & Ganley, who allegedly attempted to borrow the set of points, because he owned RONAKI at the time. Quite how, with his huge trade knowledge, Lou Wilson would come to ask such a bloody stupid question beggars belief! Good story……………………….
This boat was, as is accurately detailed above, designed and built by Chas. Bailey Jr. Why should there be a trace of doubt in that? Does olivene2013 consider him incapable of that?
AHB commissioned her for use on the Manukau and called her MANUKAU. When the new MANUKAU was built by Scholten & Brijs to replace her, she was brought back to the Waitemata by AHB in February 1967 and renamed RONAKI (sometimes rendered as RONAKI II).
PS OOPS, If I’m descending to name-drop spraying too, I should get it right!
Lou Wilson was MD of Morris, Black & Matheson, and later a director of Tappenden Motors, not WASGA.
Something deeply wrong with that story! Lou would have been tickled with the absurdity of it.
The photo above shows her at the 2014 Mahurangi Anniversary Regatta. Owned by John Foreman for approx. 20 years, John purchased her off Alan Keane & told me that he had touched base again with Alan in Port Fitzroy over Christmas and at the regatta weekend. John has been told she was built in 1927 by Chas Bailey – probably the son, Chas Bailey Jnr.
John & ww would like to near more about the ‘lady’ so if you know any details or have photos – send ww an email.
Harold Kidd Update
I think she was built by Leon Warne in 1922 for James Tombs as SHEIK. Tombs sold to Roy Browne in 1925. Browne sold to S. Harrowell in 1932 who had her largely rebuilt by Lane Motor Boat Co. which included her present bridgedeck. Harrowell renamed her LADY JOYCE. During WW2 she was in RNZN service. After the war Willie Oliver owned her for a while, which says a lot for her ability. She’s a few boats along from me at H Marina, Gulf Harbour, so I’ve been interested in her for years and I’m happy that the above provenance is correct.
27/01/2015 Updated photo (ex Ken Ricketts) of LJ leaving Gulf Harbour on-route to the 2015 Mahurangi Regatta
August 2015 – LJ hauled out at Gulf Harbour (photos ex Ken Ricketts)
Designed & built by Chas Bailey Jnr. in 1950, Lady Rae is a 12m, kauri planked , carvel bridge decker, powered by a 120hp Ford.
Given her very distinctive style , I would be keen to learn more on her past & design influences .
Harold Kidd Update
She was built for Ken Simpson of Ventnor Road, Remuera. He owned her for many years, at least as late as 1967. She seems to have been a sister ship to GALA LASS built for A.H. Hurt of St Heliers about the same time. As for design, the styling cues were in every issue of “Rudder” and “Motor-Boat and Yachting” magazines of the time and ultimately derived from mid-1930’s American automotive design. If you half shut your eyes, LADY RAE looks quite like, say, a 1936 Dodge sedan, flat windscreen and all.
