Arch Logan Dinghy – Silver Fern

Screen Shot 2020-04-11 at 5.31.17 PM

Arch Logan Sailing Dinghy – Silver Fern


Chatting with Tinopai (2hrs north of Auckland) based woody Greg Schultz he tells me advancing old age has forced him to make the reluctant decision to pass on one of my most prized possessions.
Greg built this boat about 10 yrs ago off the original 1905 Arch Logan plans (modified by Chapman1921). Construction is clinker lapstrake using 6mm ply with epoxy glued laps which gives a good lightweight watertight hull (originals leaked like sieves and weighed a ton). All other timbers are kauri and totara. He also added 3 buoyancy compartments for added safety (2 side seats & forward compartment all epoxy sealed inside). Greg commented that she has only been sailed approx. a dozen times.

The Silver Fern class (12’6″) was designed as a training boat for teenagers before they moved on to the bigger M class and is therefore almost a miniature ‘Emmie’.
Spars and rigging are s/s and sails by Fife. Pivoting centerboard and rudder for shallow water sailing. Permanent reef lines for shortening sail without coming ashore.

Woodys this is a stunning boat to both look at and sail so if you are frustrated with paying big marina fees and the hassles of organizing crew – maybe now is the time to add a woody to the fleet so that you can sail single handed or take the grand kids for a sail.

Given the lockdown if you are interested it might be best to contact Greg direct at itzgreg@yahoo.com
UPDATE – Read comments section for feedback on the boats provenance.

Ngaio – A Peek Down Below

IMG_4773

IMG_4743

IMG_4752

NGAIO – A Peek Down Below

Last weekend a few woodys gathered in Islington Bay, Rangitoto Island, one of my all time favourites was there – Ngaio the 1921, Arch Logan built, 36‘ launch owned by Jan Barraclough.
Ngaio is such a stunner she couldn’t be from any other designer / builder than Arch Logan. I got to have a peek below – enjoy 🙂
She has made several appearances on WW, links below – her restoration is well documented here.
19-03-2020 Harold Kidd Input – How interesting to see the Logan Bros’ builders’ plate on NGAIO. I assume it was put there by Arch? If so, he was keeping the LOGAN BROS name alive. Of course he would still have had a stock of their builders’ plates but I can’t quite work out his motivation in using one on NGAIO. Robin might care to comment too?
20-03-20 Robin Elliot Input –Sorry I missed this. I have been self-isolating for the past 15 years or so and now it seems the world has caught up with how peaceful it can be.

The Logan plate is Interesting. From the photos in the earlier WW posts, that plate has been there on Ngaio for some time but whether it was there at the time of launching is impossible to say. Doubtful.

I’m not sure if there is one on Doreen/Coquette – I don’t think so – but as you say why would he put one on Ngaio in 1921? He was very ‘proper’ and it just would not have been right.

I suspect that rascally his son Jack was flinging them out when he cleared out the house in Bayswater in the 1950’s and passed one over to the then owner of Ngaio; probably on the grounds that Ngaio was an Arch tweak of a general hull shape developed at Logan Bros?

Interesting that there are 4 small screw holes in the plate around its edge but some philistine has drilled two big boofy holes in the centre for a couple of bog-standard slotted screws. The two empty holes in the timber above the plate lead me to believe there was another item (a different plate?) there before the Logan plate.

It’s not strictly correct but hey, its a nice addition.

RC Yacht Racing
Yesterday while waiting to pick up a family member from the medical centres near North Shore Hosp. I wandered down to Lake Pupuke and spied a group of gents sailing their yachts in the Quarry Lake.
A very pleasant way to fill in 1/2 hr – nearly forgot about the patient 🙂

WBB0003_Banner-980x160

 Classic Wooden Launches + Classic Sailing Regatta Photos

IMG_4283

Help Needed Identifying Classic Wooden Launches

The above photo shows three launches (+ a peek on a 4th on the far left) moored in Hobson Bay, Auckland. The photo is from the Edward Double Collection (1930-1940), and comes to us via Maurice Sharp’s fb.
Can we ID the boats?
2020 CYA Classic Yacht Regatta
The annual 3 day sailing regatta is in progress and yesterday I crewed on Jason Prew’s 1904, Logan built gaffer – Wairiki in Race 1.
Now I have always heard dock chat that Wairiki was a wet boat, well folks I can confirm thats an understatement,
I think you would be dryer on a sail board 🙂 Water aside (it was warm) it was a great afternoon with nice people – Jason Prew, Steve Horsley, Micheal O’Dwyer and Joyce Talbot.
In-between waves and spray I managed to snap a few photos – a taste below – more tomorrow. Enjoy.
IMG_4330

Ariki – 1904 Logan

IMG_4344

Windhaven II – Colin Wild

IMG_4302
IMG_4323

Wairiki – Onboard foot spa

IMG_4350

Jason Prew & Steve Horsley (L>R)

IMG_4372

Race HQ @ RNZYS

IMG_4376

Mike O’Dywer, Steve Horsley, Alan Houghton

LITTLE JIM (Mk1) B7

Screen Shot 2018-12-23 at 7.48.55 PM

Screen Shot 2018-12-26 at 8.40.47 PM

LITTLE JIM (Mk1) B7

If you search the words Little Jim in the WW search box you we see numerous references to a very stunning yacht, owned these days by CYA Chairman James Mortimer. She was designed / built by Arch Logan and Bill Couldrey in 1934, photos below.
Outside of the die-hard classic yachties, few know there was another Little Jim, B7, pictured above.
This LJ was a B class Keeler owned by J. Mitchelson.
Sadly she was driven ashore and totally wrecked at Catherine Bay, Great Barrier Island, after being dismasted in a gale on Christmas Day 1934?. The only good news was that the crew of 5 escaped drowning & reached the shore.
Screen Shot 2018-12-26 at 8.37.21 PM
Screen Shot 2018-12-26 at 8.37.38 PM
07-01-2019 Input from owner – James M
Little Jim started out life as a schnapper boat in 1900 under the sail number AK1 when it was built for a fisherman named Charles Vieri. Once converted to a pleasure boat for racing and cruising by the Feltham brothers, she sailed as B7 under various owners until a syndicate including Mitchelson purchased her in 1931. It was Xmas Day of ’33 she was driven onto the rocks in Katherine Bay. The story goes that after the rig snapped in two about 6 feet above the deck, and while cutting everything away a shackle got caught between the rudder and stern post, not only making a huge sea anchor with the still half-attached sails and rig but also losing any form of steerage. They managed to get two anchors down once in Katherine Bay. These held for some hours before the warps of one then the other finally frayed under the load and she went ashore. A few items were salvaged, including the small circular porthole you can see in the current cabin top in your last photo above. Legend has it that a leg of ham washed ashore, which fed the crew on Xmas Day over a campfire in the scrub behind the bay. With the insurance payout of 230 pounds plus a generous gift from Mitchelson’s aunt, Little Jim A16 was launched on 19th November 1934, a pretty impressive feat in less than 11 months! She went on to win the Anniversary Day race just two months later and has been sailling and cruising the Waitemata and Hauraki Gulf since. For anyone interested there is a great history of the two boats captured on Peter Brooke’s boatbuilders page here: http://www.classicboating.co.uk/Little%20Jim%20H.html

Doreen > Haku > Coquette

Unknown-1

Unknown

DOREEN > HAKU > COQUETTE

The top photo above (ex Lew Redwood fb > Winkeman – Akl Museum) shows the 1912 Arch Logan built launch Doreen, named after Arch’s sister, later to became Haku & then Coquette (as she is today).

Coquette was the ‘base’ for the Logan 33 f/glass production boats.  In the second photo (ex Alan Good), we see her c.1945, sporting her WWII reporting number – 201. Also of interest in this photo is the addition of the dodger fitted in the summer of 1926/27 during Fred Cooper’s ownership period. Fred also installed a 25/40 sleeve-valve Loew-Knight engine at the same time. (details ex Harold Kidd)

You can see & read more at the links below

https://waitematawoodys.com/2013/04/15/coquette/

https://waitematawoodys.com/2018/03/29/coquette-4-sale/

Best Kiwi Woody Boating Photos Of Summer

Unknown

1307381B-F6A9-4F32-A9EE-0C4554CE0C84

Best Woody Boating Photos Of Summer

The above photos showing James & Michael Dreyer’s recently relaunched  33’ 1949 Luders designed motorboat – Laughing Lady & Jason Prew’s 1904 Arch Logan gaff rigger- Wairaki – are my 2 favourite photos from this summer. They capture what classic kiwi wooden boating is all about – fun, friendship & fraternity.

The rebirth of these woodys would not have happened without people like Jason & James & the dozens of talented, enthusiastic craftspeople & helpers that rubbed up against the projects. And amazingly both of the guys have other classic woody projects on the go – Jason is restoring (rebuilding) the 1925 Dick Lang motor launch – My Girl. And James has a Rhodes 33 sloop in restoration in the USA, that hopefully will makes its way down under one day. In the meantime he gets his sailing fix from a 1937, 31’ Yankee One Design – made of kauri here in NZ, that he co-owns with his dad, Barry.

If your interested in viewing the restoration of LL or Wairiki, just search they name in the WW search box.

  At the other end of the scale below is a short video on the 1910 Camper & Nicholson 162’ classic super yacht – Orion of the Seas, for sale in Italy. It is just magnificent but her maintenance budget would be bigger than the GDP of a lot of African nations. Enjoy the varnish porn. Tomorrow I’ll share with you my trip aboard Trinidad from Whangaroa, down the west coast of NZ to Queen Charlotte Sound, Picton.

http://www.classicyacht.tv/classic-yachts-for-sale/?utm_source=Subscribe+to+CLASSIC+YACHT+TV&utm_campaign=2ca530097f-Orion&utm_medium=email&utm_term=0_fe7f446382-2ca530097f-56204649#classic-yacht-tv-featured-classic-boat-for-sale

Rawhiti – Revisited

So far there have been over 2,000 classic wooden boat stories featured on waitematawoodys & the viewing numbers (3,300,000) have grown from a dozen people to over 80,000, I have had some loyalists from day one but the big numbers have happened in the last 2 years – so not everyone will have been exposed to all the stories. Over the Christmas / NY period I have decided to take a peek back in time & feature some of the gems from the early days. Enjoy.

Have a great holiday & remember to take the camera / phone with you & snap a photo of any woodys you see. Email them to waitematawoodys@gmail.com



Rawhiti – A Once In Your Life Time Opportunity
photos ex Classic Boat, Chris Miller, Alan H & owner

Firstly – a challenge – can anyone dispute that Rawhiti is New Zealand’s finest classic yacht afloat? From all angles she is simply beautiful, a true classic from the drawing board of Arch Logan & built by Logan Bros.
Rawhiti was completely rebuilt by Peter Brookes at Brookes Boatbuilders in 2011. For her owner Greg Lee, it was a pure labour of love, he extensively researched every aspect of the project & worked alongside Peter on a daily basis, the end result being a Logan that is better than launch day in October 1906 & thats pretty bold statement to make about a Logan.

Yachts like Rawhiti only come along once in a life time, to get the chance to buy one is even rarer. That opportunity now exists, to do that – to own this beautiful piece of New Zealand’s maritime heritage, a floating work of art.

So my 2nd challenge today is to all classic boating aficionados – gather your friends or business associates & form a syndicate, sell that bloody ugly Colin McCahn, sell a few shares, sub-divide that section – do what ever you have to do, to put the money together to acquire Rawhiti.

Interested? – read on

Without boring you with details, Rawhiti’s owner is serious about selling her & now via another business transaction has the opportunity to offer Rawhiti for sale to the right owner for a fractional of the restoration cost i.e. in the $400k range.
The time window in which the business transaction is available is short and therefore there is a limit to how long Rawhiti will be marketed in this price range. If you are interested in discussing the sale, please initially, contact the owner Greg Lee on the email address below.
For anyone with an interest in acquiring Rawhiti who is unsure what they might be doing with her in the short term (but wishing to secure the opportunity to acquire her now), her owner has had provisional discussions with Peter Brookes about storing her under cover at his yard at favourable rates.

Owner email contact:       greg-lee@xtra.co.nz

Update 29-09-2019 Below is a  sneak peek at Rawhiti when she was in Australia – the photo appeared in the Sept 1925 edition of the ‘Australian Motor Boating and Yachting Monthly. Sent in by Andrew Christie.

IMG_6571

Tawera 1935 Logan A18

Screen Shot 2017-04-14 at 1.15.43 PM



Screen Shot 2017-04-14 at 1.19.36 PM

Screen Shot 2017-04-14 at 1.19.54 PM

Screen Shot 2017-04-14 at 1.17.45 PM

TAWERA 1935 LOGAN – A18

Tawera was launched on 30th December, 1935. Tawera was designed by Arch Logan and built by Colin Wild of Stanley Bay, Devonport. Her first race was the Auckland Anniversary Regatta in January 1936.

She was Arch Logans last big cutter, measuring almost 50 feet on deck and the culmination of a number of racing keelers built at that time. As the largest of the more modern keelers from Arch Logans drawing board she represented the very best in design development and to this day still epitomises all of the racing winning and wholesome sea keeping abilities of Arch Logans designs.

Tawera is immaculate and has been extensively restored and is now considered one of the finest examples of the a keeler of the pre-WWII era. Her owner is one of the Classic Yacht Associations most loyal members & has loved her as a Logan should be & spared nothing on her maintenance & restoration. She is for sale & is I believe amazing value for money at $200k.

Her recent restoration was to the highest specification which includes the building of a new spruce mast to the original specs, new Volvo Penta engine, and redevelopment of the saloon, galley, heads and fore cabin. A new wooden spinnaker pole and wooden turning blocks on deck as well as an all new sail wardrobe consisting of Mainsail, #1, #2 genoas, asymmetric and conventional spinnakers.
Anyone interested in acquiring one of, if not, the best Logan a float could contact me on waitematawoodys@gmail.com & I’ll pass details on to the owner 🙂

Alwyn – A peek down below

Screen Shot 2017-03-14 at 4.19.38 PM

ALWYN – A Peek Down Below
I’m told Alwyn was built by Arch Logan in c.1911/12. These days she is moored in Picton & owned by Derek Stocks, who bought her about 6 months ago at Taupo, & took her to Wellington by road, & sailed her to Picton. She may have spent less than 2 years on the lake. (photos were sourced by ken ricketts)

You can see more of her exterior / read more about her provenance at the link below  – unlike a lot of classics that claim Logan DNA , this one is the real deal 🙂   https://waitematawoodys.com/2013/11/23/severn/

The Restoration of My Girl

Screen Shot 2016-08-06 at 9.24.24 AM

.THE RESTORATION OF MY GIRL

While there are few of us with the courage to even consider a project of this scope, there are even fewer with the skill set to do it. That makes Jason Prew a tad special in the classic woody boating community. A lot of us would be worried that a restoration (re-build) project like this would grind to a halt 1/2 way thru – well folks I can tell you this one won’t & as proof check out at the bottom of this story, Jason’s last project – Wairiki, his 34′ 1904 Arch Logan designed gaff rigged classic yacht.

Mr Prew is a member of the fastest growing group in the CYA – woody’s that own a classic yacht & classic motor-boat.  There are a lot of photos today but I really wanted to get across the magnitude of the job Jason has bitten off:-)
Whilst I did not pickup a hammer or a piece of sandpaper during my visit to Jason’s workshop, I have contributed – a while ago I was gifted a pair of very cool bronze nav lights & as I’m a big believer in the ‘pay-it-forward’ concept, these will be gracing My Girl on launch day 🙂
My Girl was built in 1925 by Dick Lang for C.B. “Tui” Waldron of the Wade River who commuted with her. Her square bilge design was based on one by W.H.Hand. Waldron later took her to Whangarei & she was in NAPS as Z32 out of Whangarei in WW2.

Jason purchased My Girl from the Davies  family of Te Atatu, West Auckland in December 2014, Derek & his Father Trevor were long term caretakers of My Girl, keeping her in the Whau River for many years.  After a spell on the hard where she fell into dis-repair, Jason finally persuaded Derek to part with her.

When launched she was powered by a 6 cylinder 90hp Scripps engine & was capable of over 18 knots. When purchased by Jason she had a BMC Commander engine of dubious health.  When re-launched she will be powered by a 100hp Volvo Penta, so she should be a bit of a zoom zoomer 😉

The work to date has seen 76 ribs in, 3600 copper rivets riveted, 5 new floors and 2 engine beds. As you will see in the photos there is still lots of hole filling, sanding & painting in the near future.

You can read & view much more on the restoration project at the links below – the ww one has some historical photos & the mygirl link has the whole story so far. Make sure you click on the Archives link to see everything. https://waitematawoodys.com/2014/12/12/my-girl/           http://www.my-girl.co.nz/mygirl/Welcome.html

Below is a peak at Jason’s yacht Wairiki, his last restoration project. Click this link to view more http://www.wairiki.co.nz/Wairiki1904/Welcome.html

Input from Jason Prew

Thanks for the injection of smoke up the posterior Alan but I can’t claim too much credit for Wairiki, Marco Scuderi did the bulk of the work. I was mostly the destruction/wrecking department.  My Girl is also a collaboration, especially the ribs stage.  Nathan, Steve, Andrew, Tom, mostly my brother Daniel, either holding dolly or doing the peening. Robert Brook and Paul Tingey for always being encouraging on the end of the phone when i was having an OMG I can’t work this out day, (which is quite often)  I don’t have a moaning chair perse, but i have a squab that gets utilized a lot to do the same job.

P1230027

Image 1

Trinidad > Raindance > Wairiki

Dec 2016 Staring to look like a launch again versus a canoe 🙂 Bit worried about the headroom.

img_2803

Bugger

BUGGER

The 1921 classic Arch Logan launch Ngaio got a little close to the eastern end of Flat Island (Gt Barrier) on Monday. She hit just after high tide and given the angle of the ‘dangle’  must have been going at a good pace. I understand the hole(s) were patched and she was floated off on the next tide. She is built like a brick shite house so one can imagine the only major damage would have been a few bruised egos 😉 Click photos to enlarge, sorry crappy photos, mobile phone at a distance.

I for one can not comment – a mooching speed & a big powerful runabout nearby, were my saving grace (different bricks) 🙂

15-01-2016 Owner Report

Luckily Ngaio  was only traveling at 5 knots when she hit and it happened at full high tide. As the tide dropped, Ngaio came to rest almost fully supported along her keel. Salvage operators had her refloated 3 hours before the next high tide. The only damage was to the stem plate which covered the pohutakawa stem underneath, and the sacrificial keel plate. No boards were sprung, no water was taken on, and no other damage. They don’t build boats like that, these days.
The next day she returned to Auckland from Gt Barrier, without missing a beat..

Yacht Porn – Sailing Sunday

Yacht Porn – Sailing Sunday
photos ex Jason Prew

I ‘borrowed’ the above photos off Jason’s facebook page, I’m sure he won’t mind as they are simply stunning & show off his 1904 Arch Logan classic – Wairiki, perfectly.

The photos were taken around 8.30pm on Boxing Day as Jason was sliding along at 6knots on-route to Patio Bay.

Most old things in life – including boats & people look better in the evening light & knowing Jason, these photos were most likely snapped on an iPhone which just shows how far technology has come – who needs a camera 😉

As always – click any photo to enlarge.

Link below takes you to the blogsite on the restoration of Wairiki – 100’s of photos 🙂

http://www.wairiki.co.nz/Wairiki1904/Welcome.html

Little Jim – Price Reduced

LITTLE JIM – Price Reduced

Little Jim is a rather special boat, bermudan rigged she was designed & built in 1934 by Arch Logan & Bill Couldrey.
LOA: 42’10”, LWL: 28′, BEAM: 9’1″, DRAFT: 6′

A gentlemans racer cruiser & arguably the NZ’s best classic yacht in terms of pedigree, condition &  sail-ability.
Fresh from a Peter Brooke repaint in 2014 & a full Brookes restoration 2007-2009.

Folks – not wanting to sound like a real estate sales rep but opportunities like this do not happen often, this is your chance to own a piece of NZ maritime history, presented in better-than-new condition for less than the price of a tried old Beneteau 9.85m or an old Wright 35. For around $120k LJ will be yours.
Buy it or one day you will kick your self for not leaping at this opportunity.
Link below – you can also view more photos by searching Little Jim on ww

http://www.trademe.co.nz/motors/boats-marine/yachts/keeler/auction-942245200.htm

Contact owner on 027 561 4257 or rm@drivenevents.co.nz

Rawhiti – A Once In Your Life Time Opportunity

Rawhiti – A Once In Your Life Time Opportunity
photos ex Classic Boat, Chris Miller, Alan H & owner

Firstly – a challenge – can anyone dispute that Rawhiti is New Zealand’s finest classic yacht afloat? From all angles she is simply beautiful, a true classic from the drawing board of Arch Logan & built by Logan Bros.
Rawhiti was completely rebuilt by Peter Brookes at Brookes Boatbuilders in 2011. For her owner Greg Lee, it was a pure labour of love, he extensively researched every aspect of the project & worked alongside Peter on a daily basis, the end result being a Logan that is better than launch day in October 1906 & thats pretty bold statement to make about a Logan.

Yachts like Rawhiti only come along once in a life time, to get the chance to buy one is even rarer. That opportunity now exists, to do that – to own this beautiful piece of New Zealand’s maritime heritage, a floating work of art.

So my 2nd challenge today is to all classic boating aficionados – gather your friends or business associates & form a syndicate, sell that bloody ugly Colin McCahn, sell a few shares, sub-divide that section – do what ever you have to do, to put the money together to acquire Rawhiti.

Interested? – read on

Without boring you with details, Rawhiti’s owner is serious about selling her & now via another business transaction has the opportunity to offer Rawhiti for sale to the right owner for a fractional of the restoration cost i.e. in the $400k range.
The time window in which the business transaction is available is short and therefore there is a limit to how long Rawhiti will be marketed in this price range. If you are interested in discussing the sale, please initially, contact the owner Greg Lee on the email address below.
For anyone with an interest in acquiring Rawhiti who is unsure what they might be doing with her in the short term (but wishing to secure the opportunity to acquire her now), her owner has had provisional discussions with Peter Brookes about storing her under cover at his yard at favourable rates.

Owner email contact:       greg-lee@xtra.co.nz

Restored 1921 Arch Logan Classic Motor Yacht Ngaio For Sale

Arch Logan Classic Ngaio For Sale

In 1921 at Ngataringa Bay, Devonport, New Zealand’s greatest boat designer/builder Arch Logan launched the motor yacht Ngaio that had been commissioned by owner H. Partridge.
Logan built this magnificent kauri carvel planked vessel using full length kauri planks i.e. each plank was 39′ long.

Fast forward 92 years & Ngaio was acquired by Auckland architect Ian Kohler, who with partner Lancia undertook one of the most extensive professional restorations to a classic wooden boat we have seen in recent years. Ngaio’s hull was taken back to bare timber, kauri splined & glassed. Every item of engineering & fitting on-board was either reconditioned or replaced.

The photos above & below do not do this classic justice. If you are in the market for a classic vessel – inspection of Ngaio won’t disappoint.
This is a once in a lifetime chance to acquire a piece of NZ’s maritime heritage & is presented in turn the key, sail away condition.

Call Greg Stenbeck 021 985 830 or e: gregs@gulfgroup.co.nz

PS – This is actually Saturdays post, posted early 🙂

Ngaio below as featured in the 2014/5 Classic Yacht Association Register



Is This NZ’s Finest Classic Yacht Afloat?

Little Jim – A16
42’10” LOA – 28′ LWL – 9’11” Beam – 6′ Draft

1934 bermudan-rigged gentleman’s racer / cruiser – designed by Arch Logan. Arguably New Zealand’s best classic yacht afloat in terms of pedigree, condition & sail-ability. Restored & maintained by artisan boat builder Peter Brookes.

For Sale By Negociation

More detail & photos here   https://waitematawoodys.com/2014/08/31/sailing-sunday-little-jim/

Contact owner on   rm@drivenevents.co.nz

Link to view trademe listing   http://www.trademe.co.nz/motors/boats-marine/yachts/keeler/auction-795988279.htm

Now Little Jim in the perfect world should be named Little Jim II, the original was wrecked at Great Barrier Island. Photos below (details below with the photos, date?)

Little Jim 1 wreck





Dawn

DAWN
photo ex Steve Forsman

Yesterday on ww there was some chat in the comments section about the launch Dawn. Steve Forsman commented on an existing ww post that his grandfather c.1960 had owned a small, approx. 26′, launch named Dawn, that was moored in Tauranga Harbour.

Harold Kidd commented that this was most likely yet another Dawn built by Arch Logan (allegedly) for J C Spedding c.1922 but bought by Dr. Stenhouse for game fishing at Mayor Island in 1932. She was a fast boat with a 40hp Scripps.

Steve sent me the photo above last night & speaking with Harold he commented that the reference to Arch Logan building her is from a 1932 Auckland Star piece when Spedding sold her to Dr. Stenhouse of Katikati. Bill Couldrey fitted her out for game-fishing (obviously recommended by Arch) and his uncle(?) Capt. Couldrey delivered her to Tauranga for Stenhouse.

Harold feels it’s equally likely that she was built by Logan Bros under a different name but without any photo reference has been unable to ‘squirrel’ out the detail as yet. He said that you can see a resemblance to Coquette/Logan 33 if you squint a bit. One fact nags Harold – the fact she had a Scripps engine in 1932 because Lanes were Scripps agents.
To quote Harold “too many DAWNs!”

Steve would love to hear what happened to his grandfathers boat, so if anyone can add to the above – please do.

Sailing Sunday – Little Jim

LITTLE JIM

Little Jim is a rather special boat, almost royalty – blue blood 🙂 Designed by Arch Logan & built  by Bill Couldrey in 1934 under Arch’s discerning eye.

When you start life with parents like that, when you get older & it comes time for some orthopedic surgery, only the best wooden surgeon will do – enter Peter Brookes, this artisan has worked his magic on Little Jim twice. The first time was a 2 year major refit in 2007/8, which saw strengthening work to the step and bow sections and a full interior reconfiguration. The keel was off & got new bolts & the systems were replaced or overhauled. Currently Little Jim is in Peter Brookes shed getting the finishing touches to an extensive renovation. Hopefully Little Jim’s owner Rod Marler will chip in here & walk us thru whats been happening to Little Jim over the last 12 months (photos ex Peter Brookes shed below).

And at the risk of falling off-side with the gaff-rig cohorts, Little Jim being sloop rigged is just so much more sailable (if there is such a word). No need to spend hours ringing around looking for crew, Little Jim is easily sailed by two.

When she was relaunched in 2008, Lew Barrett, one of the WoodenBoat Forum guru’s made the following comments –

“I like the textures and lightness in the handling of the interior. The glossy highlights of the trim (and the beautiful natural color of the wood) works perfectly against the subdued but flawless finishes of the cabinetry. The paneled locker doors and trim are simple but elegant. It’s exactly what we love about old wooden boats. They fully respected and retained the feel and sense of age while making her new. This is a really sensitive and demanding restoration objective to accomplish.The exterior is as clean and purposeful as the interior. It all really works to make a place you want to be.”

Our own Harold Kidd commented in 2008 at her relaunch
“it remains today an eye-catcher & a head-turner by any standards, so beautifully does form fulfill function. The aesthetics of its lines remain exquisite.

We are almost spoilt by the number of classic wooden yachts in & around our harbour, they are all special in their owners eyes but few are drop dead gorgeous – Little Jim is.

(note: Interior photos ex Chris Miller ex 2010 CYA Classic Register)

Ngaio

NGAIO

Yesterday (10/12/2013) saw the 1921 Arch Logan 36′ motor launch Ngaio relaunched after a extensive re-fit & you will note that she has returned to her original colour scheme, a dark (black) navy blue 🙂 To view Ngaio pre-refit click this link to view a youtube clip from the 2013 CYA Riverhead Hotel Cruise. You cab also view more background by searching the word Ngaio in the ww search box.

http://www.youtube.com/watch?v=nU8zPAsrGa4&feature=youtu.be

Her owners Ian Kohler & wife are CYA members & Ngaio is a spectacular addition to the classic launch fleet in Auckland.

I again quote CYA duty chairman Bruce Tantrum on Ngaio “Her beauty out of the water, as one would imagine, is complete, simple and beautiful. The hull’s multi layered accumulation of many decades of paint has been removed revealing the symmetrical artistry of master craftsman Arch Logan’s full length bare kauri planking, all in absolutely perfect condition. In the next few days, she is going to be splined and fibreglassed above the water line to preserve her.

Never again will this particular definitive testament of material, form and craftsmanship be seen, never”

I myself have a soft spot for her as she has such wonderful lines, but she is a Logan & they were rather good at knocking up these things of beauty.

Boats are like houses & everyone has their own sense of style & taste – & sometimes thats a worry, but I can happily report that the Kohler’s have enhanced all the original features in a way that Arch Logan would have approved of. As you will see from the photos, as she sits on the marina, she is still a work in progress but only needing the final touches to complete the project.

Well done.

Alwyn

ALWYN

Currently for sale on trademe. Listed as a 1927 Logan (however Harold Kidd believes she was launched in April 1910). Fully reconditioned BMC Diesel, 4 berth. Two Burner gas cooker & BBQ. Chemical toilet. Fish Finder GPS .VHF Radio. Gas Detector 120 litres diesel .120 litres water..Steady sail. Solar charging system.15k spent 4 yrs ago having cabin & decks covered in marine ply & fibre glassed by professional boat builder.

Asking $35,000, – an affordable entry into classic boating.

http://www.trademe.co.nz/Browse/Listing.aspx?id=661146172



GREAT NEWS ON THIS LOGAN FROM HAROLD – 24/11/13, read the comments section for details on the uncovering of this Logan.

Hey, this has been an extremely valuable exercise in that a “new” Logan launch has been found. If this launch IS ALWYN, then she WAS built by Arch Logan after the Logan Bros yard closed down. I was always aware that there was a launch under construction or at least ordered at the time they closed down.

So I had a good trawl today on Papers Past using a variety of key words and eventually hit the jackpot. In the NZ Herald of 10th February 1912 there is an entry saying that J. Horton Swales (who I knew had built all his own many yachts and launches until then) had had a handsome new 32ft x 7ft10in x 2ft launch built by Mr. Arch Logan of Stanley Bay. SO, Arch built THREE launches after the closure, ALWYN, DOREEN/HAKU/COQUETTE and NGAIO.

Mea culpa, mea maxima culpa and I’m delighted to have erred because we now have a new Logan. I wish I had known that when Robin and I wrote the Logan book. Mind you, I’ve found a lot more Logan boats since the book went to press, but none as significant as this one, I think.

Therefore the owner does have an ARCH LOGAN launch built in late 1911 (not 1927, but that’s relatively unimportant in the scheme of things).

That must add a heap to its intrinsic value!

Tawera

TAWERA

Seeing we have a rather important yacht race (regatta) starting today, in vessels (AC72’s) that are light years way from what we call a yacht, I thought its about time I posted some photos of the rather beautiful 1935 Arch Logan ‘Tawera’. Seen here at the CYA 2012 Classic Yacht & Launch Exhibition. Somewhere I have some interior photos which I will post when I find them, in the mean time you’ll have to take my word that down below is as smart as the topsides, a little like the cigar bar at the New York Yacht Club.

Ngaio

NGAIO
I’m pleased to be able to announce that after being ‘on-the-market’ for several years, the 1921 Arch Logan 36′ launch Ngaio now has a new owner. She passed her survey with flying colours & has been hauled out & is now safely in a shed for a major external renovation.  As part of the work she will return to her original colour scheme i.e. a dark (black) navy blue. Above are photos of her post launching (possibly taken in Devonport), today – both in the water & at her recent haul-out, a preliminary sketch of her new colour scheme & wonderful scale model built of her by CYA member Bruce Tantrum.
Also click this link to view a youtube clip from the recent CYA Riverhead Cruise.
Her new owner has already applied to join the CYA, so Ngaio will be a wonderful addition to the launch fleet.
We will follow the project with great interest.
26/07/2013 – The restoration begins, photos added of haul out & transport to her new (temporary) home – a boat shed for the work.

Weekend 1

All fittings are off, belting 50% off, mast and stack removed, paint stripping beginning.

Findings so far; pohutakawa stem, kauri carvel planking, original waterline belting line cut into hull, original color is black hull, 13 coats of paint below the belting strip, 6 above the strip.

11/08/2013 – On Bruce Tanturm’s instructions (I always do what BT’s tells me to) I visited the boat shed today & meet the new owners, pleased to report that Ngaio has fallen on her feet 🙂

To quote Bruce “Her beauty out of the water, as one would imagine, is complete, simple and beautiful. The hull’s multi layered accumulation of many decades of paint has been removed revealing the symmetrical artistry of master craftsman Jack Logan’s full length bare kauri planking, all in absolutely perfect condition. In the next few days, she is going to be splined and fibreglassed to preserve her.

Never again will this particular definitive testament of material, form and craftsmanship be seen, never”

I can happliy add that the splining & f/g will only be above the waterline.

The Gypsy Story

We have some very generous & talented people in the wider classic boating community. The story of the collision & sinking of the Arch Logan designed 1939 yacht Gypsy has been well documented & can be viewed here http://gypsy.org.nz.

Yesterday I took some photos of her out on the Waitemata. You will see the owner has gone back to a cabin top that closer matches how she looked when she was launched, we like that. Well done to everyone & to John Pryor for bringing her back from the deep.Thanks to Jason Prew for the salvage photos.AH

Coquette


Launch Number CoquetteCoquette

Coquette, 1912 Logan designed . Coquette was used to take a mould off for the popular Logan 33 f/glass replicas e.g. Lucille, Lady Dorothy, Lynette.
The early shot ( with number 201) with dodger would have been taken c. 1926

Update from Robin Elliott

Coquette was launched as Doreen in 1912, built by Arch Logan for his brother Robert, who named her Doreen after their sister.By 1915 (??) she was named Haku & renamed Coquette c1923.That b&w photo above was taken c1942 or so and carries her wartime number.

Around 1945 Bill Couldrey (one of Arch Logan’s preferred boatbuilders) was asked to modernise the cabin and superstructure and this is what we see on her today. He got the curves and proportions just right. This revamped design of Bill Couldrey’s was also copied for the GRP Logan 33’s.


Photos of her as Doreen can be viewed in the book ‘The Logans – NZ’s Greatest Boat Building Family’ & as Coquette in the book’Vintage NZ Launches’. Both books by Harold Kidd & Robin Elliott & still available in good book stores.
Photo added as Coquettee c.1964, ex Ken Ricketts 15/10/2014
 17-03-2016 photos ex trademe
