Lady Ellen Restoration June ’19 Update

LADY ELLEN RESTORATION UPDATE – JUNE 2019

Just received the above photos and story below from Bruce Mitchinson, as before, I’ll let Bruce talk you thru the report.
“Over the weekend we cleared out the boatbuilders shed ready to lay out the plywood cores for the cabin coamings, which are to be clad in Iroko inside and out.

This is the last of the major woodworking, apart from the engine box and associated trim and accessories, and fitting the coamings back on the boat.
Galley is complete ready to go in after the interior paint job.
Below deck the cabin woodwork is done and ready for paint, which is all white, with varnish door frames and jambs.

Unfortunately our painter has a hand injury so we are on the lookout for a new painter at the moment.

We also lost our engineer, Ken Jaspers, who looked after our engine through its recondition, sourced all the new parts and running gear, and had things primed ready for assembly and paint.
Ken battled bone marrow cancer for the last year and was still working on our job up to a week before he checked out.
There will be a plaque for Ken, ‘Engineer to Lady Ellen’ that will go on the bulkhead in the engine bay.
The trailer and engine which became a feature in Ken and Eileen’s driveway for over a year, is now up in the boatyard, ready for Brian to finish the assembly.
All the finished parts are stacked in the shower cubicle in the shed, ready to bolt on.

Still a lot of work to do, but it looks like a boat now.”

Lady Ellen Restoration Update – March 2019

Lady Ellen Restoration Update – March 2019

Owner Bruce Mitchinson sent in the photos above & report below:

“About half way through the interior fit out so far.
Galley joinery is complete and has been shifted back to the workshop ready for paint.
Built in electrical and navigators consoles, and the new helm station in the queue for paint too.
Down below the new cabin soles and cabin partitions are all in, apart from the partition for the head, which is made, but out of the way while the space is being made into a wet room.
Hull lining and bunk slats all prefinished, ready for fitting.
Plumbing, thru-hull fittings and holding tank all set out, in the next week or two we will have a session with the hole saws to fit all these.
New exhaust pipe fitting will go in at the same time.
We have the engine in bits and all the parts have been stripped back and primed.
Final coat of paint goes on this week so it can be reassembled and tested before it goes back in.
Electrical and fresh water plumbing coming up soon”
To see/ read more on this restoration project – enter Lady Ellen in the WW search box.
Photos below to show you how far Bruce has come with the LE project – very impressive.

Lady Ellen Restoration Update – December 2018

IMG_1036

IMG_1055

Lady Ellen Restoration Update – December 2018

Owner Bruce Mitchinson sent in the photos above & report below:

“The focus over the last few weeks has been on the exterior and cockpit. We have gone through 65 litres of high-build surfacer, and sanded half of it off, to get the topsides and below waterline fair.
Barrier undercoat applied to the topsides and another round of sanding to take out minor blemishes.
The above photos show polyurethane undercoat going on the topsides last Friday, the wet look gives a taste of what’s to come after the finishing sand and the top coat goes on later this week.
While we are on a roll, the cockpit will be painted, the deck head will be undercoated, and the interior bulkheads finished off before interior work kicks off again.
Everything is ready for the bottom paint so we might get this on before my painter goes on holiday.”
To see/ read more on this restoration project – enter Lady Ellen in the WW search box 😉

Lady Ellen Restoration Update

IMG_0890

LADY ELLEN  Restoration Update

Just had an update on Bruce Mitchinson’s Lady Ellen restoration project, I wish everyone was a s good as Bruce is in sending in work-in-progress reports 🙂

Bruces words – “Strut and rudder all back in place, below waterline fairing is going on at the moment.

Fairing done on the topsides, final fill and longboard, all over, will happen over the next few weeks.
Toe rails and beltings have been repaired and reinstalled.
Looking to undercoat topsides, deck, and below waterline early next month.
Inside we have stripped the paint off the underside of the cabin top and the decks, ready to be sprayed, along with the rest of the interior, as we move from aft, for’ard.
Cockpit complete with draining floor and seating, plenty of locker space, and gas bottle enclosure.
The existing rod steering, that used to be buried under the old water tanks, has been refurbished and can now be accessed through the new lockers.
Galley and saloon trim underway this week.
Painting inside the hull, to get ready for fitting out below deck.
Keeping the original layout apart from opening up the hanging locker into the for’ard cabin with a McGeady style window opening through the bulkhead.
No guesses as to what I will be doing this Labour weekend.”
Remember – click on photos to enlarge 😉

Lady Ellen Restoration – Report 3

IMG_0692
IMG_0723
Lady Ellen Restoration – Report 3
I have just received in the latest update from Bruce Mitchinson on Lady Ellen’s restoration – As previous,  I’ll let Bruce tell you about the work.

“Skim coat done to topsides and foredeck, bottom sanded ready for the same.

Looking sleek again now you can pick up the waterline.

Duckboard extended by 250mm and reattached, beltings and toe rails are about to go back on.
Rudder assembly is back together on new bearings and rudder tube, and the propeller strut is being fitted this week so we can bolt it up while we have easy access, and then continue with the cockpit fit out.
Demolition complete downstairs in the head and the sleeping quarters and I am scraping paint and cleaning up oil soaked planking and frames so I can continue with the white paint to the inside of the hull.
Fortunately it gets narrower up this end and so there is less area to paint.
Engine bay looks much tidier after getting the treatment, just need the engine and fuel tanks to go in so we can start setting up all of the other equipment that lives in here.”
Eggemoggin Reach Regatta – WoodenBoat magazine take a cruise thru the anchorage
A great video (link below) spotting some very nice woodys at anchor, shades of our own Mahurangi Regatta 😉





JOHN BROOKE BOOK WINNER/S

The winner of a copy of the new John Brooke book is Micheal O’Dwyer (classic yacht Janet). Robert Brooke kindly donated 2 copies of the book, so I have decided to give the 2nd copy to Graeme Finch , you submitted the best reply / entry. Well do guys. I email you for your postal address. Remember its available at Boat Books in Westhaven & on-line at the BB website.

Lady Ellen Restoration – Report 1

IMG_0149

IMG_0152

Lady Ellen’ Restoration – Report 1

I have just received an update from Bruce Mitchinson that details the amazing work being undertaken on Lady Ellen – My comment to Bruce was the she was a very lucky lady – not many launches get this amount to TLC – I’ll let Bruce tell you about the work. Photos below:

“Bilge cleanup done and engine beds re-built to remove rotten sections. New laminated floor at the back to help spread the load of the engine and gearbox, where there was very little support previously. Damaged frame ends removed and new laminated sections spliced in, to run continuous across the keelson. Foredeck re-fastened and fibreglassed to make watertight and to take out the springiness. Bulkhead linings all stripped and new plywood lining has been pre-primed and undercoated ready for installation next week. Rod steering system has been modified, using all the existing components, so that all the workings now sit below the floor, and the wheel lowered to suit the new steering position. New fuel tank beds are being fitted to support the new tanks. Only another 250 copper nails and rooves to replace and we can start painting the inside of the hull.”

You can see & read details on the past work here https://waitematawoodys.com/2017/07/14/lady-ellen-restoration/

13-06-2018 Update from Bruce Mitchinson – Report 2

One year pretty much full time and we have now started on the bits you look at.

Cabin sole framing and floorboards all fitted, and the makings of the new cockpit seating and aft storage. Up to the engine bay, working forward, painting the inside of the hull.

Second coat of epoxy wood primer on over the weekend, should be all white in two weeks’ time, and ready for the engine. Everything that makes it go has been reconditioned or replaced including new shaft bearings, new propeller shaft, and new rudder bearings. Even the windlass has had a complete overhaul, along with the starter motor and the alternators.

Two weeks ago we finished off the last of the hull fastenings and fibreglass so we are all locked up for winter and ready for fairing.

Set up the helm again so we can practice driving when we knock off for a beer at the end of the day.

Unknown-1





The Continuing Issue of Electrochemical Damage To Our Wooden Boats – Lady Ellen



The Continuing Issue of Electrochemical Damage To Our Wooden Boats

 I recently received an update from Bruce Mitchinson on the restoration work underway on his 36’,  McGeady built (c.1950) classic launch, Lady Ellen. Unfortunately the old lady has a been struck with a dose of electrolysis.

You can see when the secondary shaft log was removed, electrolysis had destroyed the planking around the plate fastenings. The same problem around the main shaft log, and strut fixings, through structural members, which were all bonded together. The affected timber has been removed and new kauri blocks glued in and around the shaft log, keel bolts and floors.

The to-do list this week includes laminating up pilularis frames insitu, to replace the 15 broken, or electrolysis affected members that have been removed.This will complete the inside structural work, below the waterline, that had been put off until things dried out enough.

Other work has seen the old fuel tank removed and a clean up around the bilge in the engine bay Following this Bruce will be working his way forward with stripping and refastening on the outside of the hull.

The shaft, prop and drive couplings have gone down to Whangaparoa for adjustment, set up, and balancing.

Hats off to Bruce for doing the best of Lady Ellen. To read more on this problem, the causes & remedies – visit Chris McMullen’s WW story – link below. Its the most referenced story on WW.

https://waitematawoodys.com/2015/05/15/electrochemical-damage-to-wood-the-marine-version-of-leaky-homes/

Read more on her past & current restoration work at the links below.

https://waitematawoodys.com/2015/06/25/mystery-launch-25-06-2015/

https://waitematawoodys.com/2017/07/14/lady-ellen-restoration/
